Arcoaire APE036
43″ × 43″ footprint
APE036, APFM024/30/36/42/48/60, GPCM18/24/30/36/42/48/60, GPFM18/24/30/36/42/48/60…
Arcoaire Curb Adapters — Every Model
Arcoaire shows up across 30 verified rooftop-unit records in the SMARTCurb atlas, from the APE036 to the RTH10/11. Model families on file include PGDA. Curb footprints on file range from 43″ × 30.5″ up to 155″ × 95″. Every adapter compiled from this data ships as fully welded 16-gauge galvanized steel, fabricated by Taylor Metals in Pitt Meadows, BC. Every page below also carries a manufacturer product photo. Positions for the supply and return openings are measured from the curb's outside corner on every record here, the same datum convention used across the whole atlas. Pick a model below to see its footprint and open it in the SMARTCurb workspace.
Arcoaire APFM024/30/36/42/48/60
46″ × 42.5″ footprint
APFM024/30/36/42/48/60(L), GPCM18/24/30/36/42, GPFM18/24/30/36/42, PAF024/30/36/42/48/60(L)…
Arcoaire CUR075/76F
68″ × 68″ footprint
CUR075/76F(L), CUR085/86F(L), CUR100/110F(L), CUR125/126F(L)
Arcoaire PAD324/30/336***A
46.5″ × 31″ footprint
PAD324/30/336***A, PAN430/436***A, PAN524***A, PGD330/336***A…
Arcoaire PAD324/330/336***C
46″ × 30.5″ footprint
PAD324/330/336***C, PAD424/30/436***C, PAD524***C, PDD330/336***C…
Arcoaire PAD342/348/360***A
47″ × 43″ footprint
PAD342/348/360***A, PAN442/448/460***A, PAN536/548/560***A, PGD342/348/360***A…
Arcoaire PAD342/348/360***C
46″ × 42″ footprint
PAD342/348/360***C, PAD442/448/460***C, PAD536/548/560***C, PDD342/348/360C…
Arcoaire PAE090/102/120/150
75.5″ × 53.5″ footprint
PAE090/102/120/150, PAH090/102/120, PAS090/120/150, PGE090/102/120/150…
